Technické specifikace
| Art.no. | 8266 | -0725 | -1020 | -1025 | -1030 | -1040 | -1050 | -1055 |
|---|---|---|---|---|---|---|---|---|
| Capacity | 07/25 | 10/20 | 10/25 | 10/30 | 10/40 | 10/50 | 10/55 | |
| Working length (w) | mm | 700 | 1040 | 1040 | 1040 | 1040 | 1040 | 1040 |
| Max sheet thickness (400N/mm²) (t) | mm | 2,5 | 2,0 | 2,5 | 3,0 | 4,0 | 5,0 | 5,5 |
| Diameter of rolls (ø) | mm | 70 | 70 | 80 | 90 | 100 | 110 | 120 |
| Net weight | kg | 380 | 400 | 400 | 440 | 665 | 700 | 745 |
| OPTIONS | ||||||||
| Hardened and ground rolls | 826677 | -0725 | -1020 | -1025 | -1030 | -1040 | -1050 | -1055 |
| Art.no. | 8266 | -1060 | -1065 | -1220 | -1225 | -1235 | -1245 | -1250 |
|---|---|---|---|---|---|---|---|---|
| Capacity | 10/60 | 10/65 | 12/20 | 12/25 | 12/35 | 12/45 | 12/50 | |
| Working length (w) | mm | 1040 | 1040 | 1290 | 1290 | 1290 | 1290 | 1290 |
| Max sheet thickness (400N/mm²) (t) | mm | 6,0 | 6,5 | 2,0 | 2,5 | 3,5 | 4,5 | 5,0 |
| Diameter of rolls (ø) | mm | 130 | 140 | 80 | 90 | 100 | 110 | 120 |
| Net weight | kg | 960 | 1015 | 440 | 490 | 725 | 770 | 825 |
| OPTIONS | ||||||||
| Hardened and ground rolls | 826677 | -1060 | -1065 | -1220 | -1225 | -1235 | -1245 | -1250 |
| Art.no. | 8266 | -1255 | -1260 | -1515 | -1520 | -1530 | -1540 | -1545 |
|---|---|---|---|---|---|---|---|---|
| Capacity | 12/55 | 12/60 | 15/15 | 15/20 | 15/30 | 15/40 | 15/45 | |
| Working length (w) | mm | 1290 | 1290 | 1540 | 1540 | 1540 | 1540 | 1540 |
| Max sheet thickness (400N/mm²) (t) | mm | 5,5 | 6,0 | 1,5 | 2,0 | 3,0 | 4,0 | 4,5 |
| Diameter of rolls (ø) | mm | 130 | 140 | 80 | 90 | 100 | 110 | 120 |
| Net weight | kg | 1055 | 1120 | 480 | 530 | 785 | 840 | 905 |
| OPTIONS | ||||||||
| Hardened and ground rolls | 826677 | -1255 | -1260 | -1515 | -1520 | -1530 | -1540 | -1545 |
| Art.no. | 8266 | -1550 | -1555 | -2010 | -2015 | -2020 | -2025 | -2030 |
|---|---|---|---|---|---|---|---|---|
| Capacity | 15/50 | 15/55 | 20/10 | 20/15 | 20/20 | 20/25 | 20/30 | |
| Working length (w) | mm | 1540 | 1540 | 2040 | 2040 | 2040 | 2040 | 2040 |
| Max sheet thickness (400N/mm²) (t) | mm | 5,0 | 5,5 | 1,0 | 1,5 | 2,0 | 2,5 | 3,0 |
| Diameter of rolls (ø) | mm | 130 | 140 | 80 | 90 | 100 | 110 | 120 |
| Net weight | kg | 1140 | 1220 | 560 | 625 | 905 | 975 | 1060 |
| OPTIONS | ||||||||
| Hardened and ground rolls | 826677 | -1550 | -1555 | -2010 | -2015 | -2020 | -2025 | -2030 |
| Art.no. | 8266 | -2035 | -2040 | -2510 | -2515 | -2520 | -2525 | -2530 |
|---|---|---|---|---|---|---|---|---|
| Capacity | 20/35 | 20/40 | 25/10 | 25/15 | 25/20 | 25/25 | 25/30 | |
| Working length (w) | mm | 2040 | 2040 | 2540 | 2540 | 2540 | 2540 | 2540 |
| Max sheet thickness (400N/mm²) (t) | mm | 3,5 | 4,0 | 1,0 | 1,5 | 2,0 | 2,5 | 3,0 |
| Diameter of rolls (ø) | mm | 130 | 140 | 100 | 110 | 120 | 130 | 140 |
| Net weight | kg | 1320 | 1425 | 1025 | 1110 | 1225 | 1500 | 1630 |
| OPTIONS | ||||||||
| Hardened and ground rolls | 826677 | -2035 | -2040 | -2510 | -2515 | -2520 | -2525 | -2530 |
